Mass Productivity QT10-15 Hydraulic Block Making machine, Direct wholesale from Factory

The QT10-15 Block Making Machine is a heavy-duty, fully automatic concrete block production line. Utilizing advanced hydraulic pressure and synchronous vibration, it is designed to mass-produce high-density hollow blocks, pavers, and curbstones from sand, cement, and industrial waste.

The name itself indicates its capabilities: “QT” stands for an automatic concrete block machine line, “10” represents the machine’s capacity to produce 10 standard hollow blocks (400 × 200 × 200 mm) in a single molding press, and “15” signifies its rapid cycle time of approximately 15 seconds.

Core Technical Specifications

• Machine Type: Fully automatic, hydraulic, and vibration-molded.
• Molding Cycle: 15 to 20 seconds per cycle.
• Vibration Force: 100 to 110kN.
• Total Power: ≈ 40 to 51 kW (depending on the specific manufacturer configuration).
• Main Host Weight: Ranges from 9.8 to 11.5 tons.
• Core Components: Typically integrates Siemens PLC and premium hydraulic systems for stable, intelligent control.

Production Capacity (Per 8-Hour Shift)

By swapping the internal modular steel molds, the QT10-15 outputs diverse brick configurations:

• Standard Hollow Blocks (400 × 200 × 200mm)
  • Pcs per Mold:10 pcs
  • Hourly Output:1800 – 2400pcs
  • Per Shift (8 Hours): 14400 – 19200pieces
• Solid Bricks (240 × 115 × 53mm)
  • Pcs per Mold: 42 – 52 pcs
  • Per Shift (8 Hours) 70,000 – 80,000pieces
• Interlocking Paver Stones (200 × 100 × 60mm)
  • Pcs per Mold: 24 – 28 pcs
  • Per Shift (8 Hours): 28,000 – 34,000 pieces
• Standard Curbstones (1000 × 300 × 150mm)
  • Pcs per Mold: 1 – 2pcs
  • Per Shift (8 Hours): 1500 – 2500 pieces

Technical Advantages

• High Density and Strength: Employs low-frequency feeding and high-frequency molding to ensure blocks reach a compressive strength of over 21 MPa.
• High Efficiency: Requires only one or two operators, dramatically reducing labor costs.
• Durable Molds: The mold boxes are made of high-manganese steel that undergoes carburization and quenching, capable of lasting over 100,000 molding cycles.
• Versatility: Highly customizable; by simply changing the mold, you can pivot production from hollow blocks to paving stones or curbstones.
• Eco-Friendly: Effectively processes a wide variety of raw materials, including fly ash, slag, construction waste, and gangue

Types of Blocks Produced

By replacing the mold, the machine can produce:

• Hollow Concrete Blocks (e.g., 2-hole or 3-hole blocks for wall construction).
• Solid Bricks.
• Interlocking Pavers / Paving Bricks (Universal solid building bricks, interlocking Dutch pavers, wave/S-shape stones, and colorful face-mix).
• Curbstones (Road-side and edge stones).
• Hydraulic Revetment Blocks (for river slope protection)

Application Fields

• Commercial and Residential Construction: Produces lightweight, insulating hollow blocks used for both load-bearing and non-load-bearing walls in high-rises and residential buildings.
• Urban Infrastructure: Supplies paving stones and curbstones for public squares, sidewalks, pedestrian zones, and parking lots.
• Civil Engineering and Landscaping: Manufactures specialized elements like square bricks for parks and interlocking blocks for highway shoulders and riverbank slope protection

Material Compatibility and Application Fields

Resource-Saving Material Mixes

The hydraulic tamping system makes the machine highly eco-friendly. It successfully binds industrial residues, drastically slashing raw material costs

• Crushed aggregate stone, quarry dust, river sand, and traditional cement.
• Industrial coal fly ash, slag, construction demolition waste, and mining gangue tailings.

Key Application Fields

• Commercial Residential and Industrial Building Construction: High-capacity sourcing of load-bearing interior and exterior blocks for skyscrapers, warehouses, and factories.
• Municipal Urban Engineering: Bulk pavement blocks for public pedestrian walks, city squares, metro access, and vehicle parking lots.
• Civil Logistics and Road Transportation: Mass-scale roadside curbstones, dividers, and highway shoulder bricks.
• Water Conservancy and Soil Conservation: Large-scale production of customized slope protection blocks utilized in canal linings, coastal dikes, and highway earth-retention barriers.
